通常,你不仅想导航到新屏幕,还想向屏幕传递数据。例如,你可能想传递关于被点击项目的信息。

记住:屏幕只是小部件。在这个例子中,创建一个 Todo 列表。当一个 Todo 被点击时,导航到一个新屏幕(小部件),该屏幕显示关于该 Todo 的信息。本指南使用以下步骤:

  1. 定义一个 Todo 类。
  2. 显示一个 Todo 列表。
  3. 创建一个详细信息屏幕,可以显示关于 Todo 的信息。
  4. 导航并传递数据到详细信息屏幕。

1. 定义一个 Todo 类

#

首先,你需要一种简单的方式来表示 Todo。在这个例子中,创建一个包含两个数据片段的类:标题和描述。

dart
class Todo {
  final String title;
  final String description;

  const Todo(this.title, this.description);
}

2. 创建一个 Todo 列表

#

其次,显示一个 Todo 列表。在这个例子中,生成 20 个 Todo 并使用 ListView 显示它们。有关列表的更多信息,请参阅使用列表指南。

生成 Todo 列表

#
dart
final todos = List.generate(
  20,
  (i) => Todo(
    'Todo $i',
    'A description of what needs to be done for Todo $i',
  ),
);

使用 ListView 显示 Todo 列表

#
dart
ListView.builder(
  itemCount: todos.length,
  itemBuilder: (context, index) {
    return ListTile(title: Text(todos[index].title));
  },
)

到目前为止,一切顺利。这将生成 20 个 Todo 并将它们显示在 ListView 中。

3. 创建一个 Todo 屏幕来显示列表

#

为此,我们创建一个 StatelessWidget。我们称之为 TodosScreen。由于此页面的内容在运行时不会改变,我们将在此小部件的范围内要求 Todo 列表。

我们将 ListView.builder 作为我们返回给 build() 的小部件的主体传递。这将把列表渲染到屏幕上,供你开始使用!

dart
class TodosScreen extends StatelessWidget {
  // Requiring the list of todos.
  const TodosScreen({super.key, required this.todos});

  final List<Todo> todos;

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('Todos')),
      //passing in the ListView.builder
      body: ListView.builder(
        itemCount: todos.length,
        itemBuilder: (context, index) {
          return ListTile(title: Text(todos[index].title));
        },
      ),
    );
  }
}

使用 Flutter 的默认样式,你可以轻松地完成工作,而不必为以后想做的事情而烦恼!

4. 创建一个详细信息屏幕来显示 Todo 的信息

#

现在,创建第二个屏幕。屏幕的标题包含 Todo 的标题,屏幕的主体显示描述。

由于详细信息屏幕是一个普通的 StatelessWidget,因此要求用户在 UI 中输入一个 Todo。然后,使用给定的 Todo 构建 UI。

dart
class DetailScreen extends StatelessWidget {
  // In the constructor, require a Todo.
  const DetailScreen({super.key, required this.todo});

  // Declare a field that holds the Todo.
  final Todo todo;

  @override
  Widget build(BuildContext context) {
    // Use the Todo to create the UI.
    return Scaffold(
      appBar: AppBar(title: Text(todo.title)),
      body: Padding(
        padding: const EdgeInsets.all(16),
        child: Text(todo.description),
      ),
    );
  }
}

5. 导航并传递数据到详细信息屏幕

#

有了 DetailScreen,你就可以执行导航了。在这个例子中,当用户点击列表中的一个 Todo 时,导航到 DetailScreen。将 Todo 传递给 DetailScreen

要在 TodosScreen 中捕获用户的点击,请为 ListTile 小部件编写一个onTap() 回调。在 onTap() 回调中,使用Navigator.push() 方法。

dart
body: ListView.builder(
  itemCount: todos.length,
  itemBuilder: (context, index) {
    return ListTile(
      title: Text(todos[index].title),
      // When a user taps the ListTile, navigate to the DetailScreen.
      // Notice that you're not only creating a DetailScreen, you're
      // also passing the current todo through to it.
      onTap: () {
        Navigator.push(
          context,
          MaterialPageRoute<void>(
            builder: (context) => DetailScreen(todo: todos[index]),
          ),
        );
      },
    );
  },
),

互动示例

#
import 'package:flutter/material.dart';

class Todo {
  final String title;
  final String description;

  const Todo(this.title, this.description);
}

void main() {
  runApp(
    MaterialApp(
      title: 'Passing Data',
      home: TodosScreen(
        todos: List.generate(
          20,
          (i) => Todo(
            'Todo $i',
            'A description of what needs to be done for Todo $i',
          ),
        ),
      ),
    ),
  );
}

class TodosScreen extends StatelessWidget {
  const TodosScreen({super.key, required this.todos});

  final List<Todo> todos;

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('Todos')),
      body: ListView.builder(
        itemCount: todos.length,
        itemBuilder: (context, index) {
          return ListTile(
            title: Text(todos[index].title),
            // When a user taps the ListTile, navigate to the DetailScreen.
            // Notice that you're not only creating a DetailScreen, you're
            // also passing the current todo through to it.
            onTap: () {
              Navigator.push(
                context,
                MaterialPageRoute<void>(
                  builder: (context) => DetailScreen(todo: todos[index]),
                ),
              );
            },
          );
        },
      ),
    );
  }
}

class DetailScreen extends StatelessWidget {
  // In the constructor, require a Todo.
  const DetailScreen({super.key, required this.todo});

  // Declare a field that holds the Todo.
  final Todo todo;

  @override
  Widget build(BuildContext context) {
    // Use the Todo to create the UI.
    return Scaffold(
      appBar: AppBar(title: Text(todo.title)),
      body: Padding(
        padding: const EdgeInsets.all(16),
        child: Text(todo.description),
      ),
    );
  }
}

或者,使用 RouteSettings 传递参数

#

重复前两个步骤。

创建详细信息屏幕以提取参数

#

接下来,创建一个详细信息屏幕,该屏幕从 Todo 中提取并显示标题和描述。要访问 Todo,请使用ModalRoute.of() 方法。此方法返回带有参数的当前路由。

dart
class DetailScreen extends StatelessWidget {
  const DetailScreen({super.key});

  @override
  Widget build(BuildContext context) {
    final todo = ModalRoute.of(context)!.settings.arguments as Todo;

    // Use the Todo to create the UI.
    return Scaffold(
      appBar: AppBar(title: Text(todo.title)),
      body: Padding(
        padding: const EdgeInsets.all(16),
        child: Text(todo.description),
      ),
    );
  }
}
#

最后,当用户点击 ListTile 小部件时,使用 Navigator.push() 导航到 DetailScreen。将参数作为 RouteSettings 的一部分传递。DetailScreen 提取这些参数。

dart
ListView.builder(
  itemCount: todos.length,
  itemBuilder: (context, index) {
    return ListTile(
      title: Text(todos[index].title),
      // When a user taps the ListTile, navigate to the DetailScreen.
      // Notice that you're not only creating a DetailScreen, you're
      // also passing the current todo through to it.
      onTap: () {
        Navigator.push(
          context,
          MaterialPageRoute<void>(
            builder: (context) => const DetailScreen(),
            // Pass the arguments as part of the RouteSettings. The
            // DetailScreen reads the arguments from these settings.
            settings: RouteSettings(arguments: todos[index]),
          ),
        );
      },
    );
  },
)

完整示例

#
dart
import 'package:flutter/material.dart';

class Todo {
  final String title;
  final String description;

  const Todo(this.title, this.description);
}

void main() {
  runApp(
    MaterialApp(
      title: 'Passing Data',
      home: TodosScreen(
        todos: List.generate(
          20,
          (i) => Todo(
            'Todo $i',
            'A description of what needs to be done for Todo $i',
          ),
        ),
      ),
    ),
  );
}

class TodosScreen extends StatelessWidget {
  const TodosScreen({super.key, required this.todos});

  final List<Todo> todos;

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('Todos')),
      body: ListView.builder(
        itemCount: todos.length,
        itemBuilder: (context, index) {
          return ListTile(
            title: Text(todos[index].title),
            // When a user taps the ListTile, navigate to the DetailScreen.
            // Notice that you're not only creating a DetailScreen, you're
            // also passing the current todo through to it.
            onTap: () {
              Navigator.push(
                context,
                MaterialPageRoute<void>(
                  builder: (context) => const DetailScreen(),
                  // Pass the arguments as part of the RouteSettings. The
                  // DetailScreen reads the arguments from these settings.
                  settings: RouteSettings(arguments: todos[index]),
                ),
              );
            },
          );
        },
      ),
    );
  }
}

class DetailScreen extends StatelessWidget {
  const DetailScreen({super.key});

  @override
  Widget build(BuildContext context) {
    final todo = ModalRoute.of(context)!.settings.arguments as Todo;

    // Use the Todo to create the UI.
    return Scaffold(
      appBar: AppBar(title: Text(todo.title)),
      body: Padding(
        padding: const EdgeInsets.all(16),
        child: Text(todo.description),
      ),
    );
  }
}
